This module offers analog inputs that are probably high-precision and can handle a wide range of temperatures. As part of the SM1231 family, it’s designed to work with sensors that have voltage or current outputs. The “5QF32” suffix might suggest it has the capability for thermocouple or millivolt inputs. It’s perfect for industrial automation, especially where monitoring temperature or process variables is essential. You’ll often find it in HVAC systems, food processing, or energy management. You can configure it using TIA Portal, which includes diagnostic features. Plus, its compact design makes it a great fit for smaller control cabinets.
Product Details:
Manufacturer Series | S7 1200 |
Pulse Transmission Output | YES |
Mounting Type | DIN Rail |
Brand | SIEMENS |
Type Code | 6ES7231-5QF32-0XB0 |
Update Rate | 25500 |
PRODUCT FAMILY | SIMATIC S71200 |
Input type | Analog Thermocouple 8 channel |
Product type designation | SM 1231, AI 8x16 bit TC |
Product Description | SIMATIC S7-1200, Analog input, SM 1231 TC, 8 AI thermocouples |
COMMUNICATION | PROFINET |
Delivery information | Export Control Regulations AL : N / ECCN : 9N9999 Estimated dispatch time (Working Days) 1 Day/Days |
